Specification
Conductor size | Ø24mm |
---|---|
Rated current | AC 100A |
Output voltage | AC 500mV/100A (AC 5mV/A) |
Accuracy | ±0.5%rdg±0.1mV (50/60Hz) ±1.0%rdg±0.2mV (40Hz - 1kHz) |
Phase shift | within ±2.0º (45 - 65Hz) |
Cable length | Approx. 3m |
Output connector | MINI DIN 6PIN |
Output impedance | Approx. 10Ω |
Applicable standards | IEC 61010-1 , IEC 61010-2-032:2002 CAT III 300V pollution degree 2 , IEC 61326 |
Operating temperature and humidity range | 0 - 50˚C , relative humidity 85% or less (no condensation) |
Dimension | 100(L) x 60(W) x 26(D) mm |
Weight | Approx. 160g |
Accessories | 9095 (Carrying case) Instruction manual , Cable marker |
Optional Accessories | 7146 (Banana Ø4 adjuster plug) 7185 (Extension Cable) |
