MULTI FUNCTION INSTALLATION TESTER
Replacement Products
Discontinued products
Continuity and Insulation Testing
• Live circuit warning LED:
Immediate illumination of a warning lamp if the circuit under test is live
• Auto Discharge:
Allows fast and safe discharge of electrical energy stored in capacitive circuits following testing
• Integral overload protection on internal continuity and insulation test circuitry
• Autoranging
• 500V DC test voltage for insulation tests
• 200mA short circuit current on continuity ranges
Loop and RCD Testing
• Wiring connection check LED’s:
Immediate indication if wiring of circuit under test is correct
• Overheat Protection:
Rapid detection of overheating of internal circuitry,display of warning signal to user and automatic halting of measurement
• Supply Voltage Indication:
Can display supply voltage value in loop impedance mode
• Low Current Loop Impedance Test:
Short duration low test current will prevent tripping of many passive RCDs
• Auto Data Hold:
Retains displayed reading for set period following test
• Phase Angle Selection:
Selection of test current from +ve or -ve half cycle of waveform can prevent tripping of polarized type RCDs
Specification
| Continuity Testing | |
|---|---|
| Measuring Ranges | 0 - 19.99 and 10.0 - 199.9Ω (2 auto ranges) |
| Open Circuit Voltage | > 4V (as per IEC 364) |
| Short Circuit Current | > 200mA DC (as per IEC 364) |
| Accuracy | ±(3% + 3dgt) |
| Loop Impedance Testing | |
| Rated Voltage | 230V AC +10%-15% (50Hz) |
| Voltage Measuring Range | 100-250V AC (50Hz) |
| Impedance Range Nominal Test Current |
20/2000Ω 25A (20Ω range) 15mA (2000Ω range) |
| Test Period | 1/2 cycle (10ms) |
| Accuracy | 20Ω range : ±(3% + 8dgt) 2000Ω range : ±(3% + 8dgt) |
| Insulation Testing | |
| Measuring Ranges | 0 - 19.99 and 10.0 - 199.9MΩ (2 auto ranges) |
| Test Voltage | 500V DC |
| Output Voltage on Open Circuit |
570V DC±6% |
| Rated Current | > 1mA (as per IEC 364) |
| Accuracy | ± (3% + 3dgt) |
| RCD Testing | |
| Rated Voltage | 230V AC +10%-15% (50Hz) |
| Trip Current Settings | RCD × 1/2: 5, 15, 50, 150, 250mA RCD × 1: 10, 30, 100, 300, 500mA |
| Trip Current Duration | RCD × 1/2 × 1: 2000ms |
| Fast Trip | 150mA |
| Accuracy | Trip current ±3% of test current at 230V. Trip time ±(3% + 3dgt) |
| Safety Standard | IEC 61010-1 CAT III 300V Pollution Degree 2 IEC 61010-2-031 IEC 61557 |
|---|---|
| Power source | R6 (AA) (1.5V) × 8 |
| Dimension | 175(L) × 115(W) × 86(D)mm |
| Weight | 780g approx. |
| Accessories | 7122B (Test leads) KAMP10* (Test Lead with IEC Connector) Pouch for Test leads Shoulder Strap Shoulder Pad R6 (AA) × 8 Instruction Manual |
| Optional Accessories | 7133B (Distribution board test leads) |
*KAMP10(EU): European SHUKO plug
KAMP10(UK): British plug(13A)
KAMP10(AU): Australian plug
KAMP10(SA): South African plug
