ANALOG INSULATION TESTER
MODEL 3166
• 1000V/2000MΩ
• Expanded megohm scale for easy reading
• New robust housing case to prevent damage
• AC voltmeter scale for easy reading
• Expanded megohm scale for easy reading
• New robust housing case to prevent damage
• AC voltmeter scale for easy reading
Insulation Resistance
| DC Test Voltage | 1000V |
|---|---|
| Max. effective scale value | 2000MΩ |
| Mid-scale value | 50MΩ |
| First effective measuring range | 2 - 1000MΩ |
| Accuracy | ±5%rdg |
| Second effective measuring range | 1/2000MΩ |
| Accuracy | ±10%rdg |
AC Voltage
| AC Voltage | 600V |
|---|---|
| Accuracy | ±3% of full scale value |
General
| Power source | R6 (AA) (1.5V) × 4 |
|---|---|
| Dimension | 90(L) × 137(W) × 40(D)mm |
| Weight | Approx. 330g |
| Accessories | 7025 (Test leads) 9074 (Cord case) 9123 (Shoulder strap) R6 (AA) × 4 Instruction Manual |
